Home > Commercial Display Products > Hanging touch all-in-one machine > Floor-standing touch screen machine > Vertical infrared touch all-in-one machine
- Product Description
- Computer system parameters
- Android system parameters
- Parameters of the Kirin system
| Category | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches |
| Model | ST43HL-P | ST49HL-P | ST55HL-P | ST65HL-P | ST75HL-P | ST86HL-P |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 |
| Processor | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G |
| Memory | 4G | 4G | 4G | 4G | 4G | 4G |
| Hard disk | 128G | 128G | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ | 350 cd/㎡ | 350 cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60HZ | 4K-60HZ | 4K-60HZ |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 51W | 82W | 92W | 112W | 288W | 288W |
| Display Size (mm) | 527.4(W)×939.2(H) | 604(W)×1074(H) | 678.4(W)×1207.6(H) | 801.5(W)×1426.5(H) | 927.6(W)×1649.2(H) | 1064.6(W)×1893.2(H) |
| Overall dimension (mm) | 601.2(W)×1800(H)×100(D) | 671.6(W)×1900(H)×100(D) | 757.2(W)×1900(H)×100(D) | 883.2(W)×1900(H)×100(D) | 1011 (W) × 2429.75(H)× 158.8(D) | 1139 (W) × 2429.75(H)× 158.8(D) |
| Packing size (mm) | 725(W)×1850(H)×176(D) | 840(W)×2000(H)×180(D) | 880(W)×1984(H)×186(D) | 1004(W)×2094(H)×181(D) | 2210 (W) × 1835(H)× 200(D) | 1349 (W) × 2640(H)× 396(D) |
| Weight (kg) | kg (net weight), 46.5kg (gross weight) | |||||
| Annex | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card |
| Category | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches |
| Model | ST43HL-A | ST49HL-A | ST55HL-A | ST65HL-A | ST75HL-A | ST86HL-A |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 |
| Processor | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz |
| Memory | 2G | 2G | 2G | 2G | 2G | 2G |
| Hard disk | 32G | 32G | 32G | 32G | 32G | 32G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 51W | 82W | 92W | 112W | 288W | 288W |
| Display Size (mm) | 527.4(W)×939.2(H) | 604(W)×1074(H) | 678.4(W)×1207.6(H) | 801.5(W)×1426.5(H) | 927.6(W)×1649.2(H) | 1064.6(W)×1893.2(H) |
| Overall dimension (mm) | 601.2(W)×1800(H)×100(D) | 671.6(W)×1900(H)×100(D) | 757.2(W)×1900(H)×100(D) | 883.2(W)×1900(H)×100(D) | 1011(W)×2429.75(H)×158.8(D) | 1139(W)×2429.75(H)×158.8(D) |
| Packing size (mm) | 725(W)×1850(H)×176(D) | 840(W)×2000(H)×180(D) | 2005(W)×920(H)×70(D) | 1004(W)×2094(H)×181(D) | 2210(W)×835(H)×200(D) | 1349(W)×2640(H)×369(D) |
| Weight (kg) | kg (net weight), 46.5kg (gross weight) | |||||
| Annex | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery |
| Category | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches |
| Model | ST43HL-GP | ST49HL-GP | ST55HL-GP | ST65HL-GP | ST75HL-GP | ST86HL-GP |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System |
| Processor | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency |
| Memory | 8G | 8G | 8G | 8G | 8G | 8G |
| Hard disk | 128G | 128G | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ | 350 cd/㎡ | 350 cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60HZ | 4K-60HZ | 4K-60HZ |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 51W | 82W | 92W | 112W | 288W | 288W |
| Display Size (mm) | 527.4(W)×939.2(H) | 604(W)×1074(H) | 678.4(W)×1207.6(H) | 801.5(W)×1426.5(H) | 927.6(W)×1649.2(H) | 1064.6(W)×1893.2(H) |
| Overall dimension (mm) | 601.2(W)×1800(H)×100(D) | 671.6(W)×1900(H)×100(D) | 757.2(W)×1900(H)×100(D) | 883.2(W)×1900(H)×100(D) | 1011 (W) × 2429.75(H)× 158.8(D) | 1139 (W) × 2429.75(H)× 158.8(D) |
| Packing size (mm) | 725(W)×1850(H)×176(D) | 840(W)×2000(H)×180(D) | 880(W)×1984(H)×186(D) | 1004(W)×2094(H)×181(D) | 2210 (W) × 1835(H)× 200(D) | 1349 (W) × 2640(H)× 396(D) |
| Weight (kg) | kg (net weight), 46.5kg (gross weight) | |||||
| Annex | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card |
