- Product Description
- Android system parameters
| Category | 15.6 inches | 18.5 inches | 21.5 inches | 23.6 inches | 32 inches | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches | 98 inches |
| Model | ST156GG-A | ST185GG-A | ST215GG-A | ST236GG-A | ST32GG-A | ST43GG-A | ST49GG-A | ST55GG-A | ST65GG-A | ST75GG-A | ST86GG-A | ST98GG-A |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 |
| Processor | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz |
| Memory | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G |
| Hard disk | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Brightness | 350cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | 400cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Contrast | 1000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz |
| Touch | None | None | None | None | None | None | None | None | None | None | None | None |
| Power (W) | 18W | 18W | 19W | 22W | 39W | 51W | 82W | 92W | 112W | 288W | 288W | 576W |
| Display Size (mm) | 343.2(W)×192.6(H) | 407.8(W)×228.4(H) | 476.8(W)×268.3(H) | 521.2(W)×293.2(H) | 697.6(W)×393.5(H) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1428.5(W)×803.5(H) | 1649.6(W)×927.9(H) | 1872(W)×1053(H) | 2157.9(W)×1213.35(H) |
| Overall dimension (mm) | 379.6(W)×240(H)×58(D) | 445.6(W)×269.6(H)×58(D) | 511.2(W)×307.8(H)×58(D) | 560.6(W)×336.1(H)×58(D) | 756.8(W)×451.8(H)×68.8(D) | 1006(W)×601(H)×80.5(D) | 1140.6(W)×671.6(H)×80.3(D) | 1284(W)×757.3(H)×80.3(D) | 1485.2(W)×862.2(H)×83(D) | 1707.4(W)×987.3(H)×83.2(D) | 1953.6(W)×1127.2(H)×94.5(D) | 2216.2(W)×1278.2(H)×106.7(D) |
| Packing size (mm) | 450(W)×310(H)×110(D) | 512(W)×341(H)×100(D) | 587(W)×388(H)×110(D) | 635(W)×415(H)×110(D) | 845(W)×550(H)×140(D) | 1075(W)×690(H)×160(D) | 1248(W)×792(H)×140(D) | 1363(W)×856(H)×140(D) | 1600(W)×1000(H)×190(D) | 1845(W)×1150(H)×215(D) | 2105(W)×1280(H)×225(D) | 2355(W)×1445(H)×225(D) |
| Weight (kg) | 4.6kg (net weight)/5.3kg (gross weight) | 12.3kg (net weight)/14.2kg (gross weight) | 32kg (net weight), 38kg (gross weight) | 43kg (net weight), 53kg (gross weight) | 63kg (net weight), 74kg (gross weight) | 88kg (net weight), 102kg (gross weight) | ||||||
| Annex | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery |
