- Product Description
- Specification parameters
| Category | 46 inches | 46 inches | 46 inches | 49 inches | 55 inches | 55 inches | 55 inches | 65 inches | 75 inches |
| Model | ST4635S-5 | ST4617S-5 | ST46J | ST4935L-5 | ST5535S-5 | ST5517S-5 | ST5588L-5 | ST6535J-5 | ST7535J-5 |
| Panel | A Gauge Panel | IPS hard screen | IPS hard screen | IPS hard screen | A Gauge Panel | IPS hard screen | IPS hard screen | IPS hard screen | ADS Hard Screen |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 |
| Brightness | 450cd/㎡ | 600cd/㎡ | 600cd/㎡ | 600cd/㎡ | 450cd/㎡ | 600cd/㎡ | 600cd/㎡ | 600cd/㎡ | 500cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 1200:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 4K-60Hz | 4K-60Hz |
| physical patchwork | 3.5mm | 1.7mm | 0.88mm | 3.5mm | 3.5mm | 1.7mm | 0.88mm | 3.5mm | 3.5mm |
| Display color | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M |
| Life | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs |
| Power (W) | ≦ 130W | ≤ 200W | ≤ 200W | ≤ 200W | ≤ 200W | ≤ 200W | ≤ 200W | ≤ 290W | 288W |
| Display Size (mm) | 1018.08(W)×572.67(H) | 1018.08(W)×572.67(H) | 1018.42(W)×572.92(H) | 1074.08(W)×604.3(H) | 1209.9(W)×680.7(H) | 1209.9(W)×680.7(H) | 1209.6(W)×680.4(H) | 1429.08(W)×804.12(H) | 1649.66(W)×927.93(H) |
| Overall dimension (mm) | 1021.78(W)×576.37(H)×89.30(D) | 1020.73(W)×575.27(H)×120.9(D) | 1019.3(W)× 573.8(H)×116.2(D) | 1077.58(W)×607.8(H)×119.2(D) | 1213.55(W)×684.35(H)×89.1(D) | 1212.4(W)×683.2 (H)×112.07(D) | 1210.48(W)×681.28(H)×111.88(D) | 1432.58(W)×807.62(H)×124.1mm | 1658.76(W)×940.04(H)×120.15(D) |
| Packing size (mm) | Double 1300(W)× 785(H)× 330(D) | ||||||||
| Weight (kg) | Single 17.5kg (net weight)/double 38.5kg (gross weight) | ||||||||
| Annex | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card | Remote control, manual, certificate/warranty card |
