Home > Commercial Display Products > Hanging touch all-in-one machine > Wall-mounted capacitive touch all-in-one computer
- Product Description
- Computer system parameters
- Android system parameters
- Parameters of the Kirin system
| Category | 15.6 inches | 18.5 inches | 21.5 inches | 23.6 inches | 32 inches | 43 inches | 49 inches | 55 inches | 65 inches |
| Model | ST156RG-P | ST185RG-P | ST215RG-P | ST236RG-P | ST32RG-P | ST43RG-P | ST49RG-P | ST55RG-P | ST65RG-P |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 |
| Processor | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G |
| Memory | 4G | 4G | 4G | 4G | 4G | 4G | 4G | 4G | 4G |
| Hard disk | 128G | 128G | 128G | 128G | 128G | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Brightness | 350cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ |
| Contrast | 1000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 4K-60HZ |
| Touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch |
| Power (W) | 18W | 18W | 19W | 22W | 39W | 51W | 82W | 92W | 112W |
| Display Size (mm) | 343.2(W)×192.6(H) | 407.8(W)×228.4(H) | 476.8(W)×268.3(H) | 521.2(W)×293.2(H) | 697.6(W)×393.5(H) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1426.5(W)×801.5(H) |
| Overall dimension (mm) | 379.6(W)×240(H)×58(D) | 445.6(W)×269.6(H)×58(D) | 511.2(W)×307.8(H)×58(D) | 560.6(W)×336.1(H)×58(D) | 756.8(W)×451.8(H)×68.8(D) | 1006(W)×601(H)×80.5(D) | 1140.6(W)×671.6(H)×80.3(D) | 1284(W)×757.3(H)×80.3(D) | 1503.6(W)×882.6(H)×82.3(D) |
| Packing size (mm) | 450(W)×310(H)×110(D) | 512(W)×341(H)×100(D) | 587(W)×388(H)×110(D) | 635(W)×415(H)×110(D) | 845(W)×550(H)×140(D) | 1075(W)×690(H)×160(D) | 1248(W)×792(H)×140(D) | 1363(W)×856(H)×140(D) | |
| Weight (kg) | 4.9kg (net weight)/5.6kg (gross weight) | ||||||||
| Annex | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card |
| Category | 15.6 inches | 18.5 inches | 21.5 inches | 23.6 inches | 32 inches | 43 inches | 49 inches | 55 inches | 65 inches |
| Model | ST156RG-A | ST185RG-A | ST215RG-A | ST236RG-A | ST32RG-A | ST43RG-A | ST49RG-A | ST55RG-A | ST65RG-A |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 |
| Processor | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz |
| Memory | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G | 2G |
| Hard disk | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G | 32G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 |
| Brightness | 350cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Contrast | 1000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz |
| Touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch |
| Power (W) | 18W | 18W | 19W | 22W | 39W | 51W | 82W | 92W | 112W |
| Display Size (mm) | 343.2(W)×192.6(H) | 407.8(W)×228.4(H) | 476.8(W)×268.3(H) | 521.2(W)×293.2(H) | 697.6(W)×393.5(H) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1426.5(W)×801.5(H) |
| Overall dimension (mm) | 379.6(W)×240(H)×58(D) | 445.6(W)×269.6(H)×58(D) | 511.2(W)×307.8(H)×58(D) | 560.6(W)×336.1(H)×58(D) | 756.8(W)×451.8(H)×68.8(D) | 1006(W)×601(H)×80.5(D) | 1140.6(W)×671.6(H)×80.3(D) | 1284(W)×757.3(H)×80.3(D) | 1503.6(W)×882.6(H)×82.3(D) |
| Packing size (mm) | 450(W)×310(H)×110(D) | 512(W)×341(H)×100(D) | 587(W)×388(H)×110(D) | 635(W)×415(H)×110(D) | 845(W)×550(H)×140(D) | 1075(W)×690(H)×160(D) | 1248(W)×792(H)×140(D) | 1363(W)×856(H)×140(D) | |
| Weight (kg) | 4.6kg (net weight)/5.3kg (gross weight) | 12.3kg (net weight)/14.2kg (gross weight) | |||||||
| Annex | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card |
| Category | 18.5 inches | 21.5 inches | 23.6 inches | 32 inches | 43 inches | 49 inches | 55 inches | 65 inches |
| Model | ST185RG-GP | ST215RG-GP | ST236RG-GP | ST32RG-GP | ST43RG-GP | ST49RG-GP | ST55RG-GP | ST65RG-GP |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System |
| Processor | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency |
| Memory | 8G | 8G | 8G | 8G | 8G | 8G | 8G | 8G |
| Hard disk | 128G | 128G | 128G | 128G | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Brightness | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 450cd/㎡ | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz | 4K-60HZ |
| Touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch |
| Power (W) | 18W | 19W | 22W | 39W | 51W | 82W | 92W | 112W |
| Display Size (mm) | 407.8(W)×228.4(H) | 476.8(W)×268.3(H) | 521.2(W)×293.2(H) | 697.6(W)×393.5(H) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1426.5(W)×801.5(H) |
| Overall dimension (mm) | 455.6(W)×269.6(H)×58(D) | 511.2(W)×307.8(H)×58(D) | 560.6(W)×336.1(H)×58(D) | 756.8(W)×451.8(H)×68.8(D) | 1006(W)×601(H)×80.5(D) | 1140.6(W)×671.6(H)×80.3(D) | 1284(W)×757.3(H)×80.3(D) | 1503.6(W)×882.6(H)×82.3(D) |
| Packing size (mm) | 512(W)×341(H)×100(D) | 585(W)×380(H)×110(D) | 635(W)×415(H)×110(D) | 832(W)×530(H)×150(D) | 1075(W)×690(H)×160(D) | 1200(W)×755(H)×160(D) | 1350(W)×848(H)×160(D) | 1685(W)×1062(H)×160(D) |
| Weight (kg) | 4.9kg (net weight)/5.6kg (gross weight) | |||||||
| Annex | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card |
