Home > Commercial Display Products > Hanging touch all-in-one machine > Infrared touch all-in-one machine
- Product Description
- Computer system parameters
- Android system parameters
- Parameters of the Kirin system
| Category | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches | 98 inches |
| Model | ST43HG-P | ST49HG-P | ST55HG-P | ST65HG-P | ST75HG-P | ST86HG-P | ST98HG-P |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 |
| Processor | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G |
| Memory | 4G | 4G | 4G | 4G | 4G | 4G | 4G |
| Hard disk | 128G | 128G | 128G | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ | 350 cd/㎡ | 350 cd/㎡ | 400cd/㎡ |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60HZ | 4K-60HZ | 4K-60HZ | 4K-60HZ |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 51W | 82W | 92W | 112W | 288W | 288W | 576W |
| Display Size (mm) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1428.5(W)×803.5(H) | 1649.6(W)×927.9(H) | 1872(W)×1053(H) | 2157.9(W)×1213.35(H) |
| Overall dimension (mm) | 1006(W)×601(H)×87(D) | 1140.6(W)×671.6(H)×86.3(D) | 1284(W)×757.3(H)×86.3(D) | 1485.2(W)×862.2(H)×83(D) | 1707.4(W)×987.3(H)×83.2(D) | 1953.6(W)×1127.2(H)×94.5(D) | 2216.2(W)×1278.2(H)×106.7(D) |
| Packing size (mm) | 1075(W)×690(H)×160(D) | 1200(W)×755(H)×160(D) | 1350(W)×848(H)×160(D) | 1600(W)×1000(H)×190(D) | 1845(W)×1150(H)×215(D) | 2105(W)×1280(H)×225(D) | 2355(W)×1445(H)×225(D) |
| Weight (kg) | 32kg (net weight), 38kg (gross weight) | 43kg (net weight), 53kg (gross weight) | 63kg (net weight), 74kg (gross weight) | 88kg (net weight), 102kg (gross weight) | |||
| Annex | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card |
| Category | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches | 98 inches |
| Model | ST43HG-A | ST49HG-A | ST55HG-A | ST65HG-A | ST75HG-A | ST86HG-A | ST98HG-A |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 |
| Processor | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz |
| Memory | 2G | 2G | 2G | 2G | 2G | 2G | 2G |
| Hard disk | 32G | 32G | 32G | 32G | 32G | 32G | 32G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | 400cd/㎡ |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 51W | 82W | 92W | 112W | 288W | 288W | 576W |
| Display Size (mm) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1428.5(W)×803.5(H) | 1649.6(W)×927.9(H) | 1872(W)×1053(H) | 2157.9(W)×1213.35(H) |
| Overall dimension (mm) | 1006(W)×601(H)×87(D) | 1140.6(W)×671.6(H)×86.3(D) | 1284(W)×757.3(H)×86.3(D) | 1485.2(W)×862.2(H)×83(D) | 1707.4(W)×987.3(H)×83.2(D) | 1953.6(W)×1127.2(H)×94.5(D) | 2216.2(W)×1278.2(H)×106.7(D) |
| Packing size (mm) | 1075(W)×690(H)×160(D) | 1200(W)×755(H)×160(D) | 1350(W)×848(H)×160(D) | 1600(W)× 1000 (high × 190(D)) | 1845(W)×1150(H)×215(D) | 2105(W)×1280(H)×225(D) | 2355(W)×1445(H)×225(D) |
| Weight (kg) | 32kg (net weight), 38kg (gross weight) | 43kg (net weight), 53kg (gross weight) | 63kg (net weight), 74kg (gross weight) | 88kg (net weight), 102kg (gross weight) | |||
| Annex | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery | Wall mount, power cord, manual, certificate/warranty card, remote control, battery |
| Category | 43 inches | 49 inches | 55 inches | 65 inches | 75 inches | 86 inches | 98 inches |
| Model | ST43HG-GP | ST49HG-GP | ST55HG-GP | ST65HG-GP | ST75HG-GP | ST86HG-GP | ST98HG-GP |
| System Architecture | Single system | Single system | Single system | Single system | Single system | Single system | Single system |
| Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System |
| Processor | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency |
| Memory | 8G | 8G | 8G | 8G | 8G | 8G | 8G |
| Hard disk | 128G | 128G | 128G | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Visual Angle | 178o | 178o | 178o | 178o | 178o | 178o | 178o |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ | 350 cd/㎡ | 350 cd/㎡ | 400cd/㎡ |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60HZ | 4K-60HZ | 4K-60HZ | 4K-60HZ |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 51W | 82W | 92W | 112W | 288W | 288W | 576W |
| Display Size (mm) | 939.2(W)×527.4(H) | 1073.9(W)×604(H) | 1207.6(W)×678.4(H) | 1428.5(W)×803.5(H) | 1649.6(W)×927.9(H) | 1872(W)×1053(H) | 2157.9(W)×1213.35(H) |
| Overall dimension (mm) | 1006(W)×601(H)×87(D) | 1140.6(W)×671.6(H)×86.3(D) | 1284(W)×757.3(H)×86.3(D) | 1485.2(W)×862.2(H)×83(D) | 1707.4(W)×987.3(H)×83.2(D) | 1953.6(W)×1127.2(H)×94.5(D) | 2216.2(W)×1278.2(H)×106.7(D) |
| Packing size (mm) | 1075(W)×690(H)×160(D) | 1200(W)×755(H)×160(D) | 1350(W)×848(H)×160(D) | 1685(W)×1062(H)×160(D) | 1865(W)×1187(H)×220(D) | 2153(W)×1327(H)×240(D) | 2416(W)×1478(H)×240(D) |
| Weight (kg) | |||||||
| Annex | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card | Wall mount, power cord, certificate/warranty card |
