- Product Description
- Computer system parameters
- Android system parameters
- Parameters of the Kirin system
| Category | 43 inches | 49 inches | 55 inches | 65 inches |
| Model | ST43RL-P | ST49RL-P | ST55RL-P | ST65RL-P |
| System Architecture | Single system | Single system | Single system | Single system |
| Operating System | WindoWs 10 | WindoWs 10 | WindoWs 10 | WindoWs 10 |
| Processor | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G | i3-4000M, dual-core 4 thread, frequency 2.4G |
| Memory | 4G | 4G | 4G | 4G |
| Hard disk | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60HZ |
| Touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch |
| Power (W) | 51W | 82W | 92W | 112W |
| Display Size (mm) | 527.4(W)×939.2(H) | 604(W)×1073.9(H) | 678.40(W)×1207.60(H) | 801.5(W)×1426.5(H) |
| Overall dimension (mm) | 601.2(W)×1800(H)×93.5(D) | 671.6(W)×1900(H)×93.5(D) | 757.2(W)×1900(H)×93.5(D) | 883.2(W)×1900(H)×93.5(D) |
| Packing size (mm) | 725(W)×1850(H)×176(D) | 804(W)×1897(H)×176(D) | 880(W)×2000(H)×186(D) | 1004(W)×2094(H)×181(D) |
| Weight (kg) | ||||
| Annex | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card |
| Category | 43 inches | 49 inches | 55 inches | 65 inches |
| Model | ST43RL-A | ST49RL-A | ST55RL-A | ST65RL-A |
| System Architecture | Single system | Single system | Single system | Single system |
| Operating System | Android 11.0 | Android 11.0 | Android 11.0 | Android 11.0 |
| Processor | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 1.8GHz | Quad-core ARM Cortex-A55 architecture, frequency 2.0GHz |
| Memory | 2G | 2G | 2G | 2G |
| Hard disk | 32G | 32G | 32G | 32G |
| Panel | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 60Hz |
| Touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch |
| Power (W) | 51W | 82W | 92W | 112W |
| Display Size (mm) | 527.4(W)×939.2(H) | 604(W)×1073.9(H) | 678.40(W)×1207.60(H) | 801.5(W)×1426.5(H) |
| Overall dimension (mm) | 601.2(W)×1800(H)×93.5(D) | 671.6(W)×1900(H)×93.5(D) | 757.2(W)×1900(H)×93.5(D) | 883.2(W)×1900(H)×93.5(D) |
| Packing size (mm) | 725(W)×1850(H)×176(D) | 804(W)×1997(H)×176(D) | 920(H)×2005(W)×70(D) | 1004(W)×2094(H)×181(D) |
| Weight (kg) | ||||
| Annex | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery | Base, power cord, manual, certificate/warranty card, remote control, battery |
| Category | 43 inches | 49 inches | 55 inches | 65 inches |
| Model | ST43RL-GP | ST49RL-GP | ST55RL-GP | ST65RL-GP |
| System Architecture | Single system | Single system | Single system | Single system |
| Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System | Genuine Kirin Operating System |
| Processor | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency | KC6000-6C-U6580 eight nuclear 2.5G main frequency |
| Memory | 8G | 8G | 8G | 8G |
| Hard disk | 128G | 128G | 128G | 128G |
| Panel | IPS | IPS | IPS | IPS |
| Resolution | 1920 × 1080 | 1920 × 1080 | 1920 × 1080 | 3840 × 2160 |
| Brightness | 500cd/㎡ | 450cd/㎡ | 450cd/㎡ | 350 cd/㎡ |
| Visual Angle | 178o | 178o | 178o | 178o |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 5000:1 |
| Scanning frequency | 60Hz | 60Hz | 60Hz | 4K-60HZ |
| Touch | Capacitive touch | Capacitive touch | Capacitive touch | Capacitive touch |
| Power (W) | 51W | 82W | 92W | 112W |
| Display Size (mm) | 527.4(W)×939.2(H) | 604(W)×1073.9(H) | 678.40(W)×1207.60(H) | 801.5(W)×1426.5(H) |
| Overall dimension (mm) | 601.2(W)×1800(H)×93.5(D) | 671.6(W)×1900(H)×93.5(D) | 757.2(W)×1900(H)×93.5(D) | 883.2(W)×1900(H)×93.5(D) |
| Packing size (mm) | 725(W)×1850(H)×176(D) | 804(W)×1897(H)×176(D) | 880(W)×2000(H)×186(D) | 1004(W)×2094(H)×181(D) |
| Weight (kg) | ||||
| Annex | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card | Base, power cord, certificate/warranty card |
