- Product Description
- Specification parameters
| Category | 55 inch | 65 inch | 75 inch | 85 inch | 86 inch | 98 inch |
| Model | ST55HY | ST65HY | ST75HY | ST85HY | ST86HY | ST98HY |
| System Architecture | dual system | dual system | dual system | dual system | dual system | dual system |
| Operating System | Android 13.0 | Android 13.0 | Android 13.0 | Android 13.0 | Android 13.0 | Android 13.0 |
| Processor | Quad-Core Cortex-A55 | Quad-Core Cortex-A55 | Quad-Core Cortex-A55 | Quad-Core Cortex-A55 | Quad-Core Cortex-A55 | Quad-Core Cortex-A55 |
| Memory | 4G | 4G | 4G | 4G | 4G | 4G |
| Hard disk | 32G | 32G | 32G | 32G | 32G | 32G |
| Panel | IPS | IPS | IPS | IPS | IPS | IPS |
| Resolution | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 | 3840 × 2160 |
| Brightness | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | 350cd/㎡ | 400cd/㎡ |
| Contrast | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Scanning frequency | 4K-60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz | 4K-60Hz |
| Camera | None | None | None | None | None | None |
| Microphone | None | None | None | None | None | None |
| Touch | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control | Infrared touch control |
| Power (W) | 90W | 112W | 288W | 288W | 360W | 576W |
| Display Size (mm) | 1209.6(W)×680(H) | 1428.5(W)×803.5(H) | 1649.6(W)×927.9(H) | 1872(W)×1053(H) | 1893.4(W)×1064.9(H) | 2157.8(W)×1213.9(H) |
| Overall dimension (mm) | 1265(W)×763.8(H)×83.8(D) | 1485.2(W)×887.9(H)×83.2(D) | 1707.4(W)×1013(H)×83.2(D) | 1953.6(W)×1152.7(H)×93(D) | 1953.6(W)×1152.7(H)×93(D) | 2217.4(W)×1305.2(H)×106(D) |
| Packing size (mm) | 1365(W)×900(H)×190(D) | 1600(W)×1000(H)×190(D) | 1845(W)×1150(H)×215(D) | 2105(W)×1280(H)×225(D) | 2105(W)×1280(H)×225(D) | 2355(W)×1445(H)×225(D) |
| Weight (kg) | 23kg (net weight), 28kg (gross weight) | 32kg (net weight), 38kg (gross weight) | 43kg (net weight), 53kg (gross weight) | 63kg (net weight), 74kg (gross weight) | 63kg (net weight), 74kg (gross weight) | 88kg (net weight), 102kg (gross weight) |
| Annex | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card | Wall mount, remote control, battery, stylus, power cord, manual, certificate/warranty card |
